1 Powering On the Equipment
a
Check the voltage and the fuse capacity of the external power supply
Standard Voltage of the Input Power Supply
Allowed Voltage Range for AC Equipment
220V 100V to 240V
Equipment Max.
Power
Consumpti
on
Max. Working
Current
Recommended Fuse Capacity Rule for Selecting a
Proper Fuse (Power
Distribution
Cabinet)
NE05E-
SG/SH/SI
35W AC: 0.8A
DC: 1.5A
AC: ≥1 A (5A is recommended.)
DC: ≥1.875 A (5A is recommended.)
•Rated working
current of fuse ≥
maximum working
current of
equipment x 1.25.
•Maintaining the
current at the
minimum value
of the fuse capacity
is recommended.
NE05E-S2 140W 4A ≥ 5A (5A is recommended.)
NE05E-SE/SF 68W 3A ≥ 3.75A (5A is recommended.)
NE05E-SQ AC: 108W
DC: 103W
AC: 2.5A
DC: 6A
AC:≥3.125A (5A is recommended.)
DC: ≥ 7.5A (10A is recommended.)
NE08E-S6 250W 8A ≥ 10A(10A is recommended.)
NE08E-S6E 350W 8A ≥ 10A(10A is recommended.)
Standard Voltage of the Input Power Supply
Allowed Voltage Range for DC Equipment
- 48 V - 38.4 V to - 57.6 V
- 60 V - 48 V to - 72 V
21
Before the equipment is powered on, you must use the multimeter to test whether a short-circuit occurs
between the positive and negative terminals of the PDU.
Powering On the Equipment
For running an AC NE05E-SQ, you must turn on the switches of both AC power modules
operating in 1+1 backup mode.
