The power
supply fails.
22
The fan is faulty.
Contact the
engineering
supervisor or
software engineer.
The board hardware
is faulty
Use the NE05E-SI as an example for an AC device:
Use the NE08E-S6 as an example for a DC device:
b
Check the power-on status
Indicator State Description
Indicator
State Description
PWR On and green The power supply is normal.
Off The power supply fails.
STAT On and green The board is working normally.
On and red The board hardware is faulty.
Off The board is not powered on or
created.
Mapping relation between indicators and their status
Indicator Indicator Status Status Description
PWR On (green) The power supply is normal.
Off The power supply fails.
FAN On (green) The fan is running normally.
On (red) The fan fails.
Off The fan is not powered on.
