E.3 Installing the Power Distribution Box into a Cabinet
This section describes how to install the power distribution box into a cabinet and install
cables.
NOTE
l An N68E whose cabinet doors and rear boards are all torn down is used.
l Related materials for providing four input lines and 12 output lines are used.
l Cables that have proper length and are equipped with terminals are used.
NOTE
l It is recommended that the wiring terminals on the power distribution box before the installation,
and the power distribution box be installed in the cabinet prior to the installation of any other device.
l The power distribution box is heavy and needs to be installed by two people.
Related Tools
Crosshead screwdriver, socket wrench, ladder, marker, and torque batch
Related Materials
Table E-3 Related materials
Material
Description Quantity
Slide rail - 2
Captive
nut
- 4
Panel bolt M6 4
Binding
strap
- -
Insulating
tape
- -
Input
terminal
of the
power
distributi
on box
Power
input cable
Wire,450/750V,60227 IEC
02(RV)150mm^2,blue,
360A(per meter)
4
Wire,450/750V,60227 IEC
02(RV)150mm^2,black,
360A(per meter)
4
Power
distribution
box
terminal
Naked Crimping Terminal,JG,
150mm^2,M12,Tin Plating
8
HUAWEI NetEngine40E Universal Service Router
Hardware Description
E DPD300-4-12 Power Distribution Box, Dual-Two Inputs
Issue 01 (2015-08-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
737
