Item Description
Dimensions (H x
W x D)
● Basic dimensions (excluding the parts protruding from
the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x
17.40 in. x 8.66 in.)
● Maximum dimensions (the depth is the distance from
ports on the front panel to the parts protruding from the
rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x
17.40 in. x 8.94 in.)
Weight
(including
packaging)
4 kg (8.8 lb)
Stack ports Not supported
RTC Not supported
RPS Not supported
PoE Not supported
Rated voltage
range
● 100 V AC to 240 V AC, 50/60 Hz
● High-voltage DC input: 240 V DC
Maximum
voltage range
● 90 V AC to 264 V AC, 47 Hz to 63 Hz
● High-voltage DC input: 190 V DC to 290 V DC
Maximum power
consumption
(100%
throughput, full
speed of fans)
43 W
Typical power
consumption
(30% of trac
load, tested
according to ATIS
standard, with
EEE enabled)
27 W
Operating
temperature
-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m
(0-5906 ft.)
NOTE
When the altitude is 1800-5000 m (5906-16404 ft.), the highest
operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.).
The equipment cannot start when the temperature is lower than 0°C
(32°F).
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 164
