Page #235 background image
Table 9-7 Technical specications
Item Description
Transceiver form factor eSFP
Transmission speed GE
Center wavelength
(nm)
850
Standards compliance 1000BASE-SX
Connector type LC
Applicable cable and
maximum transmission
distance
Multimode ber (with modal bandwidth of 160
MHz*km and diameter of 62.5 μm): 0.22 km
Multimode ber (OM1): 0.275 km
Multimode ber (with modal bandwidth of 400
MHz*km and diameter of 50 μm): 0.5 km
Multimode ber (OM2): 0.55 km
Multimode
ber (OM3): 1 km
Transmit power (dBm) -9.5 to -2.5
Maximum receiver
sensitivity (dBm)
-17.0
Overload power (dBm) 0
Extinction ratio (dB) 9
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02315204
9.2.2 SFP-GE-LX-SM1310
Table 9-8 Technical specications
Item Description
Transceiver form factor eSFP
Transmission speed GE
Center wavelength
(nm)
1310
Standards compliance 1000BASE-LX10/LH
Connector type LC
S1700 Managed Series Ethernet Switches
Product Description
9 Optical Modules
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 201
