Page #242 background imageLoading...
Page #242 background image
Table 9-17 Technical specications
Item Description
Transceiver form factor eSFP
Transmission speed GE
Center wavelength
(nm)
Rx: 1490/Tx: 1570
Standards compliance Non-standard
Connector type LC
Applicable cable and
maximum transmission
distance
Single-mode ber: 80 km
Transmit power (dBm) -2.0 to +4.0
Maximum receiver
sensitivity (dBm)
-26
Overload power (dBm) -3.0
Extinction ratio (dB) 9
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02311DDB
NO TE
This module can only be used on a switch running V200R008C00 or a later version. A
switch running an earlier version may fail to obtain information about this module.
Single-ber bidirectional (BIDI) optical modules must be used in pairs. For example, SFP-
GE-ZBXD1 must be used with SFP-GE-ZBXU1.
9.2.12 SFP-GE-ZBXU1 (Single-Fiber-Bidirectional Module)
Table 9-18 Technical
specications
Item Description
Transceiver form factor eSFP
Transmission speed GE
Center wavelength
(nm)
Rx: 1570/Tx: 1490
Standards compliance Non-standard
Connector type LC
S1700 Managed Series Ethernet Switches
Product Description
9 Optical Modules
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 208
