7 Jack for AC terminal locking latch
NOTE
The AC terminal locking latch is not
delivered with the switch.
8 AC socket
NOTE
It is used with an AC power cable.
Port Description
10/100/1000BASE-T Ethernet Electrical Port
A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s, and must use network cables. Table 3-15 describes the attributes of a
10/100/1000BASE-T Ethernet electrical port.
Table 3-15 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute
Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
Full-duplex
Maximum
transmission
distance
100 m
1000BASE-X Ethernet Optical Port
When a 1000BASE-X port uses a GE optical module, it can only transmit and receive data at
1000 Mbit/s and does not support the 100 Mbit/s transmission speed. When a 1000BASE-X
port uses a GE copper module, it can transmit and receive data at 10 Mbit/s, 100 Mbit/s, or
1000 Mbit/s. Table 3-16 describes the attributes of a 1000BASE-X Ethernet optical port.
Table 3-16 Attributes of a 1000BASE-X Ethernet optical port
Attribute
Description
Connector type LC/PC
Optical port
attributes
Depend on the module used
Standards
compliance
IEEE802.3z
Working mode Full-duplex
