Number Indicator/
Button
Color Description
Red Steady on: The system does not work
normally after registration, or a fan or
temperature alarm has been generated.
4 STAT: status
indicator
Green
l Off: The status mode is not selected.
l Steady on: The status mode (default
mode) is selected. If the status mode
is selected, the service port indicator
shows the port link or activity state.
5 SPED: speed
indicator
Green
l Off: The speed mode is not selected.
l Steady on: The speed mode is
selected. If the speed mode is
selected, the service port indicator
shows the port speed state. After 45
seconds, the service port indicators
automatically restore to the status
mode.
6 STCK: stack
indicator
NOTE
This indicator
has different
states and
meanings in
different
versions. Here is
the indicator
states and
meaning in
versions earlier
than
V200R003C00.
Green
l Off: The stack mode is not selected.
l Steady on: The service port indicators
show the stack information. After 45
seconds, the service port indicators
automatically restore to the status
mode.
l Blinking: The switch is the master
switch in a stack or a standalone
switch.
STCK: stack
indicator
NOTE
This indicator
has different
states and
meanings in
different
versions. Here is
the indicator
states and
meaning in
V200R003C00
and later
versions.
Green If you are not changing the indicator
mode (default):
l Off: The switch is in stack standby or
slave state or the stacking function is
not enabled on the switch.
l Blinking: The switch is a stack master
switch or a standalone switch with the
stacking function enabled.
