Huawei S5700 Series Hardware Description

1 Twenty 100/1000BASE-X ports
Applicable modules:
l FE optical module
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
l GE copper module
2 Four combo ports (10/100/1000BASE-T
+ 100/1000BASE-X)
Modules applicable to combo optical
ports:
l FE optical module
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
3 Four 10GE SFP+ ports
Applicable modules and cables:
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
l GE copper module
l 10GE SFP+ optical module
l 10GE-CWDM optical module
(applicable in V200R005C00 and
later versions)
l 1 m, 3 m, and 10 m SFP+ high-
speed copper cables
l 5 m SFP+ high-speed copper cable
(applicable in V200R009C00 and
later versions)
l 3 m and 10 m AOC cables
4 One mini USB port
5 One console port 6 One USB port
7 Ground screw
NOTE
It is used with a ground cable.
8 AC socket
NOTE
It is used with an AC power cable.
9 Jack for AC terminal locking latch
NOTE
The AC terminal locking latch is not
delivered with the switch.
10 RPS socket
NOTE
It is used with an RPS cable, which is not
hot swappable.
Port Description
100/1000BASE-X port
A 100/1000BASE-X port can send and receive data at 100 Mbit/s or 1000 Mbit/s. Table 3-84
describes the attributes of a 100/1000BASE-X port.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
160

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
