Capaci
ty
Vendor Model Remarks
PNY M1 Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
8 GB Netac U208 Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
Hewlett-
Packard
v225w Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
STEC SLUFD8GU2T
UI
Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
NOTE
Huawei is not responsible for maintenance service of USB flash drives purchased from other vendors.
Indicator Description
NOTE
In V200R007 and later versions, you can hold down the mode switch button for 6s and release it to start
the web initial login mode. Either of the following situations will occur:
l If the switch has no configuration file, the system attempts to enter the web initial login mode. In
this mode, the status of mode indicators is as follows:
l If the system enters the web initial login mode successfully, all mode indicators turn green
and stay on for a maximum of 10 minutes.
l If the system fails to enter the initial login mode, all mode indicators fast blink for 10
seconds and then restore to the default status.
l If the switch has a configuration file, the system cannot enter the web initial login mode. In this
case, all mode indicators fast blink for 10s, and then return to the default states.
Figure 3-33 Indicators on the S5700-28X-LI-24S-AC
CONSOLE
1 2 3 4
MODE
STCK
SPED
STAT
SYS
RPS
PWR
HUAWEI
S5700-28X-LI-24S-AC
1234567891011 12
13 14
15
16
17 18 19 20
21
22
23 24
21 22 23 24
10G/1G
1
8
910
7
23
654
MODE
STCK
SPED
STAT
SYS
RPS
PWR
HUAWEI
S5700-28X-LI-24S-AC
1234567
1
7
23
654
118
CONSOLE
2 3 4
10G/1G
9108
118
8
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
