Attribute Description
Working mode GE/10GE auto-sensing
Full-duplex
Console port
The console port is connected to a console for on-site configuration. The port must use a
console cable. The console port is used when a switch is powered on for the first time. For
details about the attributes of a console port, see Table 3-86.
Table 3-86 Attributes of a console port
Attribute
Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200 bit/s
Default value: 9600 bit/s
Mini USB port
The mini USB port is connected to a console for on-site configuration. When both the Mini
USB and console port have a cable connected, only the Mini USB port works.
USB port
The USB port can have a USB flash drive connected to upgrade the switch, or transfer
configuration files or other files. The USB flash drive used on a switch must comply with
USB 1.1 and support the Linux operating system. Table 3-87 lists the USB flash drives
applicable to a switch.
Table 3-87 USB flash drives applicable to a switch
Capaci
ty
Vendor Model Remarks
4 GB Netac U208 You can buy Netac USB 4 GB flash drives
from Huawei or other vendors.
SanDisk Cruzer Blade Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
Hewlett-
Packard
v218G Huawei does not offer this USB flash drive,
and you must buy it from other vendors.
