Numbe
r
Indicator/
Button
Color Description
7 MODE: mode
switch button
-
l When you press this button once, the
service port indicators change to the
speed mode and show the speed of
each service port.
l When you press this button a second
time, the service port indicators
change to the stack mode and show
the stack ID of the local switch.
l When you press this button a third
time, the service port indicators
restore to the default mode, and the
STAT mode turns green.
If you do not press the MODE button
within 45 seconds, the service port
indicators restore to the default mode. In
this case, the STAT indicator is steady
green, the SPED indicator is off, and the
STCK indicator is off or blinking green.
8 Service port
indicator
NOTE
Arrowheads
show the
positions of
ports. A down
arrowhead
indicates a port
at the bottom,
and an up
arrowhead
indicates a port
at the top.
Meanings of service port indicators vary in different modes.
For details, see Table 3-89.
9 Mini USB
indicator
Green
l Off: The Mini USB port is not active,
and the console port is active.
l Steady on: The Mini USB port is
active.
When this indicator is on, the console
indicator is off.
10 Console
indicator
Green
l Off: The console port is not active,
and the Mini USB port is active.
l Steady on (default): The console port
is active.
When this LED is on, the Mini USB port
indicator is off.
