Table 3-89 Description of service port indicators in different modes (two indicators for each
port)
Display Mode Color Description
Status - Off: The port is not connected or has
been shut down.
Green Steady on: The port is connected.
Yellow Blinking: The port is sending or receiving
data.
Speed Green and
yellow
l Off: The port is not connected or has
been shut down.
l Both steady on:
10M/100M/1000M port: The port is
operating at 10/100 Mbit/s.
1000M/10GE port: The port is
operating at 1000 Mbit/s.
l Both blinking:
10M/100M/1000M port: The port is
operating at 1000 Mbit/s.
1000M/10GE port: The port is
operating at 10 Gbit/s.
Stack Green and
yellow
l Off: Service port indicators do not
show the stack ID of the switch.
l If both indicators are steady on, the
switch is not a master switch:
– If the indicator of a port is steady
on, the number of this port is the
stack ID of the switch.
– If the first nine port indicators are
steady on, the stack ID of the
switch is 0.
l If both indicators are blinking, the
switch is a master switch:
– If the indicator of a port is
blinking, the number of this port is
the stack ID of the switch.
– If the first nine port indicators are
blinking, the stack ID of the switch
is 0.
Power Supply Configuration
The S5700-28X-LI-24S-AC has a built-in power module and does not support pluggable
power modules. It can connect to an RPS1800 power supply for power redundancy.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
167
