Table 3-120 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
Full-duplex
Maximum
transmission
distance
100 m
10GE SFP+ port
A 10GE SFP+ Ethernet optical port supports auto-sensing to 1000 Mbit/s. It sends and
receives service data at 1000 Mbit/s or 10 Gbit/s. Table 3-121 describes the attributes of a
10GE SFP+ Ethernet optical port.
Table 3-121 Attributes of a 10GE SFP+ port
Attribute
Description
Connector type LC/PC
Optical port
attributes
Depend on the optical module used
Standards
compliance
IEEE802.3ae
Working mode GE/10GE auto-sensing
Full-duplex
Console port
The console port is connected to a console for on-site configuration. The port must use a
console cable. The console port is used when a switch is powered on for the first time. For
details about the attributes of a console port, see Table 3-122.
Table 3-122 Attributes of a console port
Attribute
Description
Connector type RJ45
Standards
compliance
RS-232
