Table 3-130 Description of indicators on the switch
Numbe
r
Indicator/
Button
Color Description
1 PWR: internal
power supply
indicator
- Off: The switch is powered off.
Green Steady on: The switch is powered on.
Yellow Steady on: The built-in power module is
faulty, and the switch is powered by the
RPS system.
2 RPS: RPS
power supply
indicator
- Off: No RPS is connected to the switch.
Green
l Steady on: The RPS is in cold backup
state.
l Blinking: The RPS is providing power
for another device.
Yellow Blinking: The RPS is providing power
for the switch and the built-in power
module of the switch is faulty.
3 SYS: system
status indicator
- Off: The system is not running.
Green
l Fast blinking: The system is starting
or is copying the system software and
configuration file from a USB flash
drive during a USB-based upgrade.
l Slow blinking: The system is running
normally.
Yellow Blinking: The switch has restarted after a
successful upgrade using a USB flash
drive. You can remove the USB flash
drive from the switch.
Red
l Steady on: The system does not work
normally after registration, or a fan or
temperature alarm has been generated.
l Blinking: The system cannot be
upgraded after a USB flash drive is
inserted. The USB-based upgrade
failed.
4 STAT: status
indicator
Green
l Off: The status mode is not selected.
l Steady on: The status mode (default
mode) is selected. If the status mode
is selected, the service port indicator
shows the port link or activity state.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
209
