Number Indicator/
Button
Color Description
2 RPS: RPS
power supply
indicator
- Off: No RPS is connected to the switch.
Green
l Steady on: The RPS is in cold backup
state or forced power-on state.
l Blinking: The RPS is providing power
for another device.
Yellow
l Steady on: The RPS is in alarm state.
(No 870 W PoE power module is
available in the RPS1800 or the
RPS1800 cannot provide power
supply to the local switch at this
time.)
l Blinking: The RPS is providing power
for the switch and the built-in power
module of the switch is faulty.
3 SYS: system
status indicator
- Off: The system is not running.
Green
l Fast blinking: The system is starting.
l Slow blinking: The system is running
normally.
Red Steady on: The system does not work
normally after registration, or a fan or
temperature alarm has been generated.
4 STAT: status
indicator
Green
l Off: The status mode is not selected.
l Steady on: The status mode (default
mode) is selected. If the status mode
is selected, the service port indicator
shows the port link or activity state.
5 SPED: speed
indicator
Green
l Off: The speed mode is not selected.
l Steady on: The speed mode is
selected. If the speed mode is
selected, the service port indicator
shows the port speed state. After 45
seconds, the service port indicators
automatically restore to the status
mode.
6 STCK: stack
indicator
Green If you are not changing the indicator
mode (default):
l Off: The switch is in stack standby or
slave state or the stacking function is
not enabled on the switch.
l Blinking: The switch is a stack master
switch or a standalone switch with the
stacking function enabled.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
227
