Display Mode Color Description
Speed Green
l Off: The port is not connected or has
been shut down.
l Steady on:
10M/100M/1000M port: The port is
operating at 10/100 Mbit/s.
1000M/10GE port: The port is
operating at 1000 Mbit/s.
l Blinking:
10M/100M/1000M port: The port is
operating at 1000 Mbit/s.
1000M/10GE port: The port is
operating at 10 Gbit/s.
PoE - Off: The port does not provide PoE
power.
Green Steady on: The port is providing PoE
power.
Yellow
l Steady on: The PoE function is
disabled on the port.
l Blinking: A PoE fault has occurred.
For example, an incompatible PD is
connected to the port.
Green and
yellow
Blinking green and yellow alternately:
The port cannot provide power to a PD.
The possible reasons include:
l The power of the PD exceeds the
maximum power or power threshold
of the port.
l The total power consumption of PDs
has reached the maximum power of
the switch.
l The manual power management mode
is used and the port is not enabled to
provide power to the PD.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
230
