Huawei S5700 Series Hardware Description

Number Indicator/
Button
Color Description
9 Service port
indicator
l GE electrical
ports: The
ports are
numbered
from bottom
to top and
left to right,
starting with
1.
l 10GE optical
ports: Each
port has an
indicator
above it.
Meanings of service port indicators vary in different modes.
For details, see Table 3-145.
10 Mini USB
indicator
Green
l Off: The Mini USB port is not active,
and the console port is active.
l Steady on: The Mini USB port is
active.
When this indicator is on, the console
indicator is off.
11 Console
indicator
Green
l Off: The console port is not active,
and the Mini USB port is active.
l Steady on (default): The console port
is active.
When this LED is on, the Mini USB port
indicator is off.
Table 3-145 Description of service port indicators in different modes (one indicator for each
port)
Display Mode
Color Description
Status Green
l Off: The port is not connected or has
been shut down.
l Steady on: The port is connected.
l Blinking: The port is sending or
receiving data.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
229

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
