Huawei S6700 Series

Model Transmis
sion
Distance
(km)
Standard Fiber Type
SFP-10G-BXD1
(bidirectional single-mode
fiber)
≤ 10
10GBase-
BX
SFP-10G-ZR
Limiting
≤ 80
10Gbase-
ZR
SFP-10G-iLR
NOTE
This module can only be
used on a switch running
V200R008C00 or a later
version. If it is used on a
switch running a version
earlier than V200R008C00,
the switch may fail to read
optical module information.
≤ 1.4
10GBASE-
iLR
Table 7-8 Optical parameters of 10GE SFP+ optical modules
Model Center
Wavelen
gth (nm)
Transmit
Power
(dBm)
Receiver
Sensitivit
y (dBm)
Overload
Optical
Power
(dBm)
Extinc
tion
Ratio
(dB)
SFP-10G-USR 850
-7.3 to -1.0
≤ -10.7
0.5
≥ 3.0
OSXD22N00 1310
-6.5 to 0.5
≤ -6.5
1.5
≥ 3.5
OMXD30000 850 -7.3 to -1.0
≤ -11.1
-1.0
≥ 3.0
OSX010000 1310 -8.2 to 0.5
≤ -12.6
0.5
≥ 3.5
OSX040N01 1550 -4.7 to 4.0
≤ -14.1
-1.0
≥ 3
SFP-10G-BXU1
(bidirectional single-mode
fiber)
RX1330/
TX1270
-8.2 to 0.5
≤ -14.4
0.5
≥ 3.5
SFP-10G-BXD1
(bidirectional single-mode
fiber)
RX1270/
TX1330
-8.2 to 0.5
≤ -14.4
0.5
≥ 3.5
SFP-10G-ZR
Limiting
1550 0 to 4.0
≤ -24.0
-7.0
≥ 9
SFP-10G-iLR 1310 -8.2 to 0.5
≤ -14.4
0.5
≥ 3.5
