Huawei S6700 Series

10GE-CWDM Optical Module
Table 7-9 lists the attributes of 10GE coarse wavelength division multiplexing (CWDM) optical
modules.
Table 7-9 Attributes of 10GE-CWDM optical modules
Center
Waveleng
th (nm),
Model
1471,
SFP-10G-
ZCW1471
1491,
SFP-10G-
ZCW1491
1511,
SFP-10G-
ZCW1511
1531, SFP-10G-
ZCW1531
1551,
SFP-10G-
ZCW1551
1571,
SFP-10G-
ZCW1571
1591,
SFP-10G-
ZCW1591
1611, SFP-10G-
ZCW1611
Attributes
and
Paramete
rs
Encapsulation type: SFP+
Transmission distance: 70 km
Fiber mode, connector type: single-mode, LC
Standard: CWDM
Operating temperature: 0°C to 70°C
l Transmit power: 0 dBm to 4.0 dBm
l Receiver sensitivity: ≤ -23.0 dBm
l Overload optical power: -7.0 dBm
l Extinction ratio: ≥ 8.2 dB
7.4.3 QSFP+ Modules
Appearance
Figure 7-6 shows the appearance of a QSFP+ optical module.
