l If the ONU fails to be in the up state, that is, Run state is offline, the physical line may
be broken or the optical transceiver may be damaged. You need to check both the
material and the line.
l If the ONU state fails, that is, Config state is failed, the ONU capability set outmatches
the actual ONU capabilities. In this case, run the display ont failed-configuration
command in the diagnosis mode to check the failed configuration item and the failure
cause. Then, rectify the fault according to actual conditions.
NOTE
If an ONT supports only four queues, the values of 4-7 of the priority-queue parameter in the gem add
command are invalid. After configuration recovers, Config state will be failed.
6. Configure the management channel from the OLT to the ONU.
NOTE
Only when the OLT remotely manages the ONU through SNMP, the management channel needs to be
configured. When the OLT remotely manages the ONU through OMCI, the management channel need
not be configured.
a. Configure the inband management VLAN and IP address of the OLT.
To remote log in to the ONU and configure the ONU from the OLT, you must
configure the inband management VLANs and IP addresses of the OLT and the ONU
on the OLT.
Create management VLAN 8, and configure the inband management IP address to
192.168.50.20/24.
huawei(config)#vlan 8 smart
huawei(config)#port vlan 8 0/19 0
huawei(config)#interface vlanif 8
huawei(config-if-vlanif8)#ip address 192.168.50.20 24
huawei(config-if-vlanif8)#quit
b. Configure the inband management VLAN and IP address of the ONU.
Configure the static IP address of the ONU to 192.168.50.2/24 and the management
VLAN ID to 8 (the same as the management VLAN of the OLT).
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont ipconfig 1 1 ip-address 192.168.50.2 mask
255.255.255.0 manage-vlan 8
c. Configure an inband management service port.
Configure the management service port ID to 0, management VLAN ID to 8, GEM
port ID to 0, and CVLAN ID to 8. The rate of the inband service port on the OLT is
not limited. Therefore, use traffic profile 6 (default). To limit the rate of the service
port, run the traffic table ip command to add a traffic profile and bind it to the service
port.
huawei(config)#service-port 0 vlan 8 gpon 0/3/1 ont 1 gemport 0 multi-
service
user-vlan 8 rx-cttr 6 tx-cttr 6
7. Confirm that the management channel between the OLT and the ONU is available.
l On the OLT, run the ping 192.168.50.2 command to check the connectivity to the ONU.
The ICMP ECHO-REPLY packet from the ONU should be received.
l You can remote log in to the ONU from the OLT to perform the configuration.
8. Create a service port.
Configure the Data service port ID to 1, SVLAN ID to 100, GEM port ID to 1, CVLAN
ID to 100. Rate limitation for upstream and downstream packets is performed on the ONU
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1812
