instead of on the OLT. Therefore, use traffic profile 6 (default). To limit the rate of the
service port, run the traffic table ip command to add a traffic profile and bind it to the
service port.
The CVLAN must be the same as the upstream VLAN of the ONU.
huawei(config)#service-port 1 vlan 100 gpon 0/3/1 ont 1 gemport 1 multi-
service
user-vlan 100 rx-cttr 6 tx-cttr 6
9. Configure queue scheduling.
Use the 3PQ+5WRR queue scheduling. Queues 0-4 adopt the WRR mode, with the weights
of 10, 10, 20, 20, and 40 respectively; queues 5-7 adopt the PQ mode.
Queue scheduling is a global configuration. You need to configure queue scheduling only
once on the OLT, and then the configuration takes effect globally. In the subsequent phases,
you need not configure queue scheduling repeatedly when configuring other services.
huawei(config)#queue-scheduler wrr 10 10 20 20 40 0 0 0
Configure the mapping between queues and 802.1p priorities. Priorities 0-7 map queues
0-7 respectively.
For the service board that supports only four queues, the mapping between 802.1p priorities
and queue IDs is as follows: priorities 0 and 1 map queue 1; priorities 2 and 3 map queue
2; priorities 4 and 5 map queue 3; priorities 6 and 7 map queue 4.
huawei(config)#cos-queue-map cos0 0 cos1 1 cos2 2 cos3 3 cos4 4 cos5 5 cos6 6
cos7 7
10. Save the data.
huawei(config)#save
Step 2 Configure the ONU.
NOTE
Because the management VLAN and the management IP address have been configured, you can remote log in
to the ONU from the OLT to perform the configuration.
1. Log in to the ONU to perform the configuration.
On the OLT, you can remote log in to the ONU to perform the configuration. User name:
root (default). Password: mduadmin (default).
2. Create a VLAN.
huawei(config)#vlan 100 smart
3. Add an uplink port to the VLAN.
Add uplink port 0/0/0 to the VLAN.
huawei(config)#port vlan 100 0/0 0
4. Create a service port.
Create service port 2. Its user VLAN ID is untagged and service VLAN ID is 100. Use the
default traffic profile (traffic profile 6). To limit the traffic rate, run the traffic table ip
command to configure the traffic profile.
huawei(config)#service-port 2 vlan 100 eth 0/1/1 multi-service user-vlan
untagged rx-cttr 6
tx-cttr 6
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1813
