Item Data
VLAN plan Single VLAN tag:
l VLAN ID: 300
l VLAN type: smart
l VLAN attribute: common
l UVLAN ID: 45
VLAN translation policy:
l ONU: Upstream packets of the HGW carry the user
VLAN and the ONU transparently transmits the
packets.
l OLT: implements VLAN translation: U<->S.
Voice parameter
IP address of the SIP server: 200.200.200.200/24
Port ID of the SIP server: 5060
User phone number: 77730010
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query the existing traffic profiles in the
system. If the existing traffic profiles in the system do not meet the requirements, run
the traffic table ip command to add a traffic profile.
Set the profile name to fttd_voip and do not limit the upstream and downstream rates.
Set the priority to 5 and packets are scheduled according to the priority carried.
huawei(config)#traffic table ip name fttd_voip cir off priority 5 priority-
policy
local-setting
2. Configure the mapping relationship between a GEM port and a VLAN.
The service flow of user VLAN 45 is mapped to GEM port 12 in the ONU line profile.
NOTE
The user VLAN is the VLAN in the packets sent from the HGW to the ONU, that is, the UVLAN.
huawei(config)#ont-lineprofile gpon profile-name fttd
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 45
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
3. Configure the VLAN of the VDSL2 port on the ONU.
If the ONU is connected to the HGW through VDSL2 port 1, add VDSL2 port 1 to
VLAN 45 in the ONU service profile.
huawei(config)#ont-srvprofile gpon profile-name fttd
huawei(config-gpon-srvprofile-1)#port vlan vdsl 1 45
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
801
