4. Create a service VLAN and add an upstream port to it.
Add upstream port 0/19/0 to VLAN 300.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
5. Create service flows.
Set the service VLAN to 300, GEM port ID to 12, and user VLAN to 45, and use
traffic profile fttd_voip.
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 1 gemport 12 multi-
service
user-vlan 45 inbound traffic-table name fttd_voip outbound traffic-table
name
fttd_voip
6. Enable the ARP proxy function.
Voice media streams for different users of the same SVLAN fail to interchange
because the service ports of the smart VLAN are isolated from each other. Therefore,
the ARP proxy function needs to be enabled on the OLT.
huawei(config)#arp proxy enable
huawei(config)#interface vlanif 300
huawei(config-if-vlanif300)#arp proxy enable
huawei(config-if-vlanif300)#quit
7. Save the data.
huawei(config)#save
l Configure the HGW.
1. Log in to the Web configuration interface.
a. Enter http://192.168.1.1 (default IP address) in the address bar of the browser
and press Enter.
b. In the login window, enter the user name and password (the default value is
provided by ISP) of the administrator and click OK.
2. Configure parameters of the voice service.
The configuration procedure is as follows:
a. In the Web page, choose Network > Bandwidth Configuration from the
navigation tree.
b. Create WAN Connection 2 for the VoIP service and set the parameters as follows:
Parameter Value
Bearing
service
VoIP
Enabling
status
Enable
VLAN mode VLAN Transparent Transmission
VLAN ID VLAN ID corresponding to the user VLAN value for voice
service flows created on the OLT. In this example, set this
parameter to 45.
802.1p Enabled
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
802
