7.1 Cabinet with Routed Cables (DC)
This document describes cable routing using the N63E-22 cabinet as an example. This cable
routing also applies for the IEC cabinets (19-inch) or racks.
81
79
35
27
25
24
37
38
Top of the cabinet (top view)
Cable hole for
power cables
Front door side
Cable hole for
fibers, clock
cables, network
cables, and trunk
cables
Cable hole for
upstream fibers
7 Routing Cables
Installation
positions for
floating nuts
9
