Huawei SmartAX MA5800-X7 User Manual

3 Appearance and Structure
The MA5800-X7 service subrack is 6 U high, and has a fan tray at the right. The subrack is
installed in the cabinet through the ETSI or IEC mounting ears.
Fan tray
Universal interface board
Service board
Power board
Grounding point
Control board
Mounting ear
Mounting ear
Cable Manager
ESD jack
535.0
242.2
268.7
287.8
442.0
263.9
482.6
242.2
268.7
287.8
442.0
263.9
With IEC (19 inch) mounting ear
With ETSI (21 inch) mounting ear
Unit: mm
Unit: mm
3
