Huawei SUN2000-12KTL-M5 Series User Manual

Item SUN2000-15
KTL-ZHM5
SUN2000-17
KTL-ZHM5
SUN2000-20
KTL-ZHM5
SUN2000-25
KTL-ZHM5
Maximum
short-circuit
current per
MPPT
40 A
Minimum
startup
voltage
200 V
MPPT voltage
range
200–1000 V
Full-load
MPPT voltage
range
410–800 V 440–800 V 480–800 V 530–800 V
Rated input
voltage
600 V
Maximum
number of
inputs
4
Number of
MPPTs
2
Note a: The maximum input voltage is the maximum DC input voltage that the
inverter can withstand. If the input voltage exceeds this value, the inverter may
be damaged.
Output
Item
SUN2000-15
KTL-ZHM5
SUN2000-17
KTL-ZHM5
SUN2000-20
KTL-ZHM5
SUN2000-25
KTL-ZHM5
Rated output
power
15000 W 17000 W 20000 W 25000 W
Maximum
apparent
power
16500 VA 18700 VA 22000 VA 27500 VA
Maximum
active power
(cosφ = 1)
16500 W 18700 W 22000 W 27500 W
Rated output
voltage
220 V/380 V, 3W/N+PE
230 V/400 V, 3W/N+PE
239.6 V/415 V, 3W/N+PE
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 10 (2024-05-14) Copyright © Huawei Digital Power Technologies Co., Ltd. 73
