Huawei SUN2000-12KTL-M5 Series User Manual

Item SUN2000-15
KTL-ZHM5
SUN2000-17
KTL-ZHM5
SUN2000-20
KTL-ZHM5
SUN2000-25
KTL-ZHM5
Maximum
output
voltage at
long-term
operation
See standards about the local power grid.
Rated output
current
22.8 A/380 V
21.7 A/400 V
20.9 A/415 V
25.8 A/380 V
24.5 A/400 V
23.7 A/415 V
30.4 A/380 V
28.9 A/400 V
27.8 A/415 V
38.0 A/380 V
36.1 A/400 V
34.8 A/415 V
Maximum
output
current
25.2 A/380 V
23.9 A/400 V
23.1 A/415 V
28.6 A/380 V
27.1 A/400 V
26.1 A/415 V
33.6 A/380 V
31.9 A/400 V
30.8 A/415 V
42.0 A/380 V
39.9 A/400 V
38.5 A/415 V
Output
voltage
frequency
50 Hz/60 Hz
Power factor 0.8 leading... 0.8 lagging
Output DC
component
DCI
< 0.25% of the rated output
Maximum
total
harmonic
distortion AC
THDI
< 3% under rated conditions. Single-order harmonic meets the
VDE4105 requirements.
Protection
Item
SUN2000-15
KTL-ZHM5
SUN2000-17
KTL-ZHM5
SUN2000-20
KTL-ZHM5
SUN2000-25
KTL-ZHM5
Overvoltage
category
PV II/AC III
Input DC
switch
Supported
Anti-islanding
protection
Supported
Output
overcurrent
protection
Supported
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 10 (2024-05-14) Copyright © Huawei Digital Power Technologies Co., Ltd. 74

Huawei SUN2000-12KTL-M5 Series Specifications

General

Brand	Huawei
Model	SUN2000-12KTL-M5 Series
Category	Inverter
Language	English
