General| Model | SUN2000-20KTL-M2 |
|---|---|
| Type | String Inverter |
| Max. efficiency | 98.6% |
| European efficiency | 98.3% |
| Max. input voltage | 1100 V |
| Max. input current per MPPT | 26 A |
| Number of MPPTs | 2 |
| Rated output power | 20, 000 W |
| Start Voltage | 200 V |
| MPPT Voltage Range | 200 V - 1000 V |
| Max. AC Power | 22, 000 VA |
| Output Frequency | 50 Hz / 60 Hz |
| Dimensions (W x H x D) | 525 x 470 x 262 mm |
| Weight | 25 kg |
| Operating Temperature Range | -25°C to +60°C |
| Cooling Method | Natural Convection |
| Protection Degree | IP65 |
| Rated AC Voltage | 230 V / 400 V |
| Max. Input Power | 30, 000 W |
| Max. Output Power | 22, 000 W |
| Rated Output Voltage | 230 V / 400 V |
