A Grid Codes
NO TE
The grid codes are subject to change. The listed codes are for reference only.
Table A-1 SUN2000-(15KTL-25KTL)-ZHM5 grid codes
No. Grid Code Description SUN2000-
15KTL-
ZHM5
SUN2000
-17KTL-
ZHM5
SUN2000-
20KTL-
ZHM5
SUN2000-2
5KTL-
ZHM5
1 NB/T 32004 China Golden
Sun low-voltage
power grid
Supported Supported Supported Supported
2 CHINA-LV220/380 China low-
voltage power
grid
Supported Supported Supported Supported
Table A-2 SUN2000-(12KTL-25KTL)-M5 grid codes
No.
Grid Code Description SUN20
00-12K
TL-M5
SUN200
0-15KTL
-M5
SUN200
0-17KTL
-M5
SUN200
0-20KTL
-M5
SUN200
0-25KTL
-M5
1 TAIPOWER Taiwan Power
low-voltage
power grid
Support
ed
Support
ed
Support
ed
Support
ed
Support
ed
2 OMAN Oman low-
voltage power
grid
Support
ed
Support
ed
Support
ed
Support
ed
Support
ed
3 Pakistan Pakistan power
grid
Support
ed
Support
ed
Support
ed
Support
ed
Support
ed
SUN2000-(12KTL-25KTL)-M5 Series
User Manual A Grid Codes
Issue 03 (2023-02-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 94
