Figure 4-10 Securing the mounting bracket
----End
4.5 Installing the Inverter
Preparing for the Installation
Before installing the inverter, take it out from the packing case and move it to the
installation position.
Handles are packed in a tting bag and are not delivered with the inverter.
Figure 4-11 Taking out and moving the inverter
SUN2000-(196KTL-H0, 200KTL-H2, 215KTL-H0)
Series
User Manual 4 Installation
Issue 08 (2021-09-30) Copyright © Huawei Technologies Co., Ltd. 27
