Figure 4-2 Minimum installation clearance
The minimum installation clearance shown in Figure 4-2 must be provided in any installation
scenario, including wall-mounted and support-mounted scenarios.
Multiple SUN2000s must be installed in a line if sufficient space is available. Otherwise,
they must be installed in checkerboard mode as shown in Figure 4-3. The stacked
installation mode shown in Figure 4-4 is not recommended. The clearance between
SUN2000s must meet requirements shown in the following figures.
