Huawei SUN2000-4.95KTL-JPL1 - Page 16

Connecting a CT Terminal
Insert the CT
terminal into the
base.
Use a
screwdriver to
tighten the
screws to
secure the
terminal.
CT terminal
Do not
reversely
connect
the CT
terminal.
Connecting the PE Cable to the CT Terminal
•
The CT terminal needs to be purchased separately.
•
Connect the CT terminals based on the cable labels.
15
Shield layer grounding
