HUAWEI TE40&TE50&TE60 Videoconferencing
Endpoint
Administrator Guide
4 Display Device and Camera
Issue 01 (2013-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
42
Output Mode
Video Resolution
x 1200), 1920 x 1200 pixels, 720p, 1080i, and 1080p
HDMI
720p, 1080i, and 1080p
2 PC OUT
VGA
800 x 600 pixels, 1024 x 768 pixels, 1280 x 1024 pixels, UXGA (1600
x 1200), 1920 x 1200 pixels, 720p, and 1080p
YPbPr
720p, 1080i, and 1080p
DVI
800 x 600 pixels, 1024 x 768 pixels, 1280 x 1024 pixels, UXGA (1600
x 1200), 1920 x 1200 pixels, 720p, 1080i, and 1080p
HDMI
720p, 1080i, and 1080p
2 SD OUT
CVBS
NTSC and PAL
S-VIDEO
NTSC and PAL
3 DVR OUT
DVI
800 x 600 pixels, 1024 x 768 pixels, 1280 x 1024 pixels, UXGA (1600
x 1200), 1920 x 1200 pixels, 720p, 1080i, and 1080p
HDMI
720p, 1080i, and 1080p
4 3G-SDI OUT
SDI
720p, 1080i, and 1080p
Although video is smoother at a higher refresh rate, the refresh rate you select must be
supported by the display device used.
Table 4-7 lists the refresh rates available for each video resolution.
Table 4-7 Available refresh rates for each resolution
Video
Resolution
Refresh Rate (Hz)
NTSC
60
PAL
50
800 x 600
pixels
56, 60, 72, 75, or 85
1024 x 768
pixels
60, 70, 75, or 85
1280 x 1024
pixels
60, 75, or 85
UXGA (1600 x
60
