Huawei Telecom Power TP48200A-DT19C2 User Manual

TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
A Technical Specifications
Issue 03 (2019-11-15)
Copyright © Huawei Technologies Co., Ltd.
99
A.8 Bluetooth Controller Specifications
Table A-8 Bluetooth controller specifications
Item
Specifications
Rated current
4 A
Rated voltage
125 V
Operating voltage upper threshold
200 V AC
Maximum endured voltage within 1 minute
1500 V AC
Insulation resistance (500 V DC)
1500 Mohms
Contact resistance (1 A DC current)
3 Mohms
Dimensions (H x W x D)
193 mm x 110 mm x 90 mm
Operating temperature
-45°C to +85°C
A.9 Intelligent Electric Meter Specifications
Table A-9 Intelligent electric meter specifications
Item
Specifications
Dimensions (L x W x H)
72 mm x 76 mm x 63 mm
Database update
1s
Voltage measurement range

Line voltage: 30-600 V AC

Phase voltage: 20-400 V AC
Continuous overload voltage
800 V AC
Current measurement range
200 mA to 100 A
Single phase power measurement range
0-48000 W/var/VA
Total power measurement range
0-96000 W/var/VA
Frequency measurement range
45-60 Hz
Power factor measurement range
-1 to 1
Current precision
0.5% (10-100 A)
Voltage precision
0.5% (20-400 V); line voltage: 1.0%
Power precision
1.0%
Power factor precision
1.0%
Frequency precision
45-60 Hz
