Table 3-1 Indicators that turn on after the router is powered on
Indicator Color Status Indicates
Power Green On The router is powered on.
Internet Green On
A physical connection is set up between the
WAN interface of the router and the Ethernet
interface of an Ethernet device (such as an
ADSL modem) through a network cable and
you can access the Internet through the
router.
Red On
A physical connection is set up between the
WAN interface of the router and the Ethernet
interface of an Ethernet device (such as an
ADSL modem) through a network cable, but
you cannot access the Internet through the
router.
NOTE
In this case, you need to configure the router as
described in chapter 4 "Configuration of Internet
Access Parameters."
WLAN Green On The WLAN function is enabled.
LAN1–LAN4 Green On
