6-28 Issue 01 (2012-10-26)
1. Log in to the Web-based configuration utility of router A.
2. In the navigation tree, choose Basic > WLAN.
The WLAN configuration page is displayed.
3. Click WLAN.
4. Select Enable WLAN.
5. Set the following parameters.
− Channel: 1
− SSID Index: SSID1
− SSID: mySSID
− Security: WPA-PSK/WPA2-PSK
− WPA pre-Shared key: MyPassword@2012
− WPA encryption: AES
6. Click Submit.
Step 3
Configure the WDS function of router A.
1. In the navigation tree, choose Basic > WLAN.
The WLAN configuration page is displayed.
2. Click WLAN WDS.
3. Select Enable.
4. Select Repeater for WDS Mode.
5. Click New.
6. Select mySSID for Select SSID.
