2012 series Tooling (HK969) Alcoa Fastening Systems
8
The 2012 is shipped with a plastic plug in the
air inlet connector. Connector has 1/4-18 female
pipe threads to accept the hose fitting. Quick con-
nect fittings and 1/4 inch inside diameter air hose
are recommended. An air supply of 90-100 psi,
capable of 2.9 CFM, must be available. Air supply
should be equipped with a filter-regulator-lubricator
unit.
1. Remove plastic plug from air inlet connector and
drop in a few drops of Automatic Transmission
Fluid, DEXRON Ill, or equivalent.
2. Screw quick-connect fitting into air inlet connec-
tor.
3. Set air pressure on regulator to 90-100 psi.
4. Attach optional air hose, part number 115436
(supplied with tool), to air inlet connector.
5. Connect air hose to tool.
6. Cycle tool a few times by depressing and releas-
ing trigger.
7. Disconnect air hose from tool.
8. Remove retaining nut.
9. Select correct nose assembly from the available
SELECTION CHARTS or speak with your Huck
representative.
NOTE: Quick disconnect fittings and air hoses
are not available from Huck.
NOTE: 2O12V is sold with the ribbed vacuum control
ON/OFF slide in the forward or OFF position. See
FIGURE 6 for slides location which is shown in the
ON (rear) position. While Tool is not being used,
move slide to the OFF (forward) position to prevent
unnecessary air loss.
Blind Fastener Installation:
The Fastener may be placed either in the work hole
or in the end of the Nose Assembly. In either case,
Tool and Nose Assembly must be held against work
and at right angles to it. Depress Trigger and hold it
depressed until Fastener is installed and Pintail
breaks. Release Trigger.
WARNING
As applicable, do not use without deflectors
or pintail bottles. If deflectors are removed or
damaged, separated pintails may eject forcibly
from rear of tool. Unshielded eyes, especially,
may be permanently injured. Other severe
injuries can be caused by flying pintails. If
there is any chance of a projectile-like ejec-
tion, always point rear of tool in a safe direc-
tion, or be sure there is some structure that
will stop ejecting pintails.
CAUTION: Insert Pintail Tube 124448-2 into
tool ONLY when using a Nose Assembly
that installs either -04 or -05 size fasteners.
Jammed pintails and damage may result if
Pintail Tube and fastener size do not corre-
spond correctly.
WARNING
To avoid pinch points, be sure there is
adequate clearance for tool and operator’s
hands before proceeding. Tool moving toward
structure may crush hands or fingers between
tool and structure if clearance is limited.
WARNING
Inspect tool for damage before each use. Do not
operate if damaged as severe personal injury
may occur.
Broken pintails eject from deflector with speed
and force. Be sure pintail deflector is directed
safely away from operator or other personnel in
the area. Ejecting pintails striking anyone may
cause serious personal injury. For Models
2012B and 2012V, pintail bottles must always be
used. Replace damaged pintail deflectors and
bottles as serious personal injury may occur
from pintails when using these defective parts.
P
P
REPARATION
REPARATION
FOR
FOR
U
U
SE
SE
O
O
PERATING
PERATING
I
I
NSTRUCTIONS
NSTRUCTIONS
