2025 Series Pneudraulic Installation Tools (HK1006) Alcoa Fastening Systems & Rings
Models
2025V & 2025LV
speCIfICatIons
STROKE: 0.675 in. (1.715 cm)
WEIGHT: 5 lbs 12oz (2.608 kg)
MAX AIR PRESSURE: 90 psi (6.2 BAR)
MAX FLOW RATE: 8.5 scfm (241 l/m)
POWER SOURCE: 90 psi (6.2 BAR) MAX
shop air
MAX OPERATING TEMP: 125° F (51.7° C)
PULL CAPACITY:
5290 lbs @ 90 psi (23.531 kN @ 6.2 BAR)
SPEED / CYCLES: 30 per minute
HOSE KITS: Use only genuine HUCK
Hose Kits rated @ 10,000 (689.5 BAR) psi
working pressure.
HYDRAULIC FLUID:
Hydraulic uid shall meet DEXRON III,
DEXRON VI, MERCON, Allison C-4
or equivalent ATF specications. Fire-
resistant uid may be used if it is an ester-
based uid such as Quintolubric HFD or
equivalent. Water-based uid shall NOT be
used as serious damage to equipment will
occur.
