244 series Pneudraulic Installation Tools (HK989)Alcoa Fastening Systems & Rings
5
INCHES
(cm)
Power Source: 90 psi shop air
Hydraulic Fluid: Hydraulic uid shall meet DEXRON
III, DEXRON VI, MERCON, Allison C-4 or equivalent
ATF specications.
Fire resistant uid may be used if it is an ester based
uid such as Quintolubric HFD or equivalent. Water
based uid shall NOT be used as serious damage to
equipment will occur.
• Stroke: .562 in (1.43 cm) at full load with losses
• Weight: 5 lbs 11 oz (2.58 kg)
• Max Air Pressure: 90 psi (6.2 BAR)
• Max Flow Rate: 6.3 scfm (178 L/m)
• Capacity: 4606 lbs (20.49 kN) @ 90 psi (6.2 BAR)
• Speed/Cycles: 30 per minute
• Max Operating Temp: 125°F (52°C)
