244 series Pneudraulic Installation Tools (HK989) Alcoa Fastening Systems & Rings
The Model 244 series Installation Tools are shipped with a
plastic plug in the air inlet connector. The connector has
1/4-18 female pipe threads to accept the air hose tting.
Quick disconnect ttings and 1/4” inside diameter air hose
are recommended. An air supply of 90-100 psi capable of 6.3
CFM must be available. Air supply should be equipped with a
lter-regulator-lubricator unit.
1. Remove plastic shipping plug from Air Inlet Connector
and put in a few drops of Automatic Transmission Fluid,
DEXRON III, or equivalent.
2. Screw quick disconnect tting into Air Inlet Connector.
3. Set air pressure on regulator to 90-100 psi.
4. Attach optional Air Hose (Huck part number 115436),
supplied with tool, to air inlet connector.
5. Connect air hose to tool.
6. Cycle tool a few times by depressing and releasing trigger.
7. Disconnect air hose from tool.
8. Remove Retaining Nut and Stop. (244X only)
9. Select proper Nose Assembly for fastener to be installed.
10. 244OSX Model:
Set stroke required for Nose Assembly selected. Refer
to Adjust Stroke section of this manual for adjustment
procedure (Fig 11).
11. 244X Model:
Attach Nose Assembly per Nose Assembly Data Sheet.
244OSX Model:
Attach nose assembly per instructions on page 21 of
this manual (Fig 12).
12. Connect air hose to tool and install fastener(s) in test
plate of proper thickness with proper size holes. Inspect
fastener(s).
NOTES:
1 Air quick disconnect ttings and air hoses are not
available from Huck International, Inc.
2 On old style nose assemblies with lock collars, Loctite®
243 threadlocker (Huck P/N 508567) should be used on
collet threads, since there is no staking hole provided on
the pull piston. Refer to nose assembly data sheets.
* Threadmate is a registered trademark of Parker Intangibles LLC
* TEFLON is a registered trademark of DuPont Corp.
* Loctite is a registered trademark of Henkel Corporation, U.S.A.
CAUTION: Do not use TEFLON® tape on
pipe threads. Pipe threads may cause tape
to shred resulting in tool malfunction.
(Threadmate™ is available from Huck in a
4oz. tube as part number 508517.)
LOCKBOLT® FASTENER INSTALLATION:
Place pin in work hole and place collar over pin. See
WARNING. (If Collar has only one tapered end, that end
must be out toward tool, not next to sheet.) Hold pin and
push nose assembly onto pin protruding through collar
until nose assembly anvil touches collar. Depress trigger
and hold depressed until collar is swaged and pintail
breaks. Release trigger and tool will go into return stroke.
The tool and nose assembly are ready for the next fastener
installation cycle.
BLIND FASTENER INSTALLATION:
Remove excess gap from between the sheets to
permit correct fastener installation. Fastener may be placed
in work hole or in end of nose assembly. See WARNING. In
either case, tool and nose assembly must be held against
work and at right angles to it. Depress trigger and hold
it depressed until fastener is installed and pintail breaks.
Release trigger and tool will go into its return stroke.
The tool and nose assembly are ready for next fastener
installation cycle.
READ ALL WARNINGS AND CAUTIONS PRIOR TO USING YOUR SYSTEM. Failure to understand
WARNINGS may cause serious personal injury. Failure to understand CAUTIONS may cause damage to
structure and Tool. Additional safety information can be found on page 4.
CAUTION: Remove excess gap from
between the sheets. This permits enough
pintail to emerge from collar for ALL jaw
teeth to engage with pintail. If ALL teeth
do not engage properly, jaws will be
stripped and/or damaged.
WARNING: Do not pull on a pin without a
collar. The pin will eject with velocity and
force when the pintail breaks off. This may
cause serious injury.
WARNING: Do not pull on a fastener’s pin
without rst placing fastener In a work piece.
The fastener will eject forcibly when the pintail
breaks off. This may cause serious Injury.
CAUTION: To avoid structural and Tool
damage, be sure enough clearance is allowed
for nose assembly at full stroke. Do not abuse
the tool by dropping it, using it as a hammer
or otherwise causing unnecessary wear and
tear. Reasonable care of installation tools by
operators is an Important factor in maintaining
tool efciency and reducing downtime.
