3585 Series Hydraulic Installation Tools (HK1080) Howmet Fastening Systems
DESCRIPTION
SPECIFICATIONS
HYDRAULIC FLUID:
® ®
Quintolubric
®
DEXRON is a registered trademark of General Motors Corp.
MERCON is a registered trademark of Ford Motor Corp.
Quintolubric is a registered trademark of Quaker Chemical Corp.
POWER SOURCE: Powerig Hydraulic Unit
HOSE KITS: Use only genuine H
10,000 psi (689.5 BAR) working pressure.
3585 SERIES DIMENSIONS:
(not including hose, cord, or nose assembly)
Inches Centimetres
Length 8.63 21.9
Width 1.88 4.80
Height 6.50 1.65
MAX OPERATING TEMP: 125°F (51.7°C)
MAX FLOW RATE: 2 gpm (7.5 l/m)
MAX PULL PRESSURE: 7400 psi (510 BAR)
MAX RETURN PRESSURE: 2200 psi (152 BAR)
PULL CAPACITY: 45,668 7400 psi
(203 kN @ 510 BAR)
STROKE:
3585: 1.81 inches (4.60 cm)
3585PT: 1.90 inches (4.83 cm)
WEIGHT: 19 lbs (8.62 kg)
The 3585 series Hydraulic Installation Tools are cylinder-and-piston assemblies. They are complete with handle, hoses,
®
Hydraulic Unit (model
918 or equivalent); nose assemblies are available separately.
These tools install a variety of fasteners.
MODEL 3585
• installs -16 (1/2”) to -24 (3/4”) Pintail-style
Lockbolt Fasteners
• has a pintail ejector to eject broken pintails from
the nose assembly
• has a nose adapter and retaining rings for
attaching nose assemblies
MODEL 3585PT
• installs -16 (1/2”) to -24 (3/4”) Huck-Spin, Huck-
Spin2
®, and Bob-Tail® Fasteners
•
fasteners without a pintail break)
• has a pass-through hole (on the piston) to allow
the included T-wrench to install Huck-Spin collars
The tools have a dump valve—positioned by the piston—that relieves the hydraulic pressure at both ends (PULL and
.
T-124833CE) to check and set the
pressures. The gauge is available separately and includes instructions for use.
NOTE: Gauge instructions are also included in applicable Powerig instruction manuals.
