HuddleCamHD HuddleView - Rear View of Camera

Ver. 1.1 – 4-19
Page5
Back of the Camera .
1. Audio Line in
a. Embeds over IP Stream
2. Network Connection
a. Allows for software connection & RTSP/RTMP Streaming
3. DVI-D Connection
4. 3G-SDI Connection
5. VISCA Connection
a. Allows for joystick control of camera
6. USB 3.0 Connection
a. Note: IP Stream, DVI-D, 3G-SDI, & USB 3.0 connections are all simultaneous
7. DC12V Power Connection
1
2
3
4
5
6
7
