Huffy 700c - Reflector Installation; Front and Rear Reflector Installation

16
Front and Rear Refl ector Installation
g 12
33
30
1. Position REAR Refl ector (33) so it
points straight backwards.
2. Tighten Clamp Screw.
NOTE: Do not over-tighten. This will
damage the Clamp.
1. Position FRONT Refl ector (30) so it
points straight forward.
2. Tighten Clamp Screw.
NOTE: Do not over-tighten. This will
damage the Clamp.
Testing Seat Clamp and Post Clamp Tightness - continued
• If the Seat Post (10) moves in the Seat Tube (B) (Screw Clamp):
• Loosen the clamp Screw (A).
• Put the seat in the correct position
and tighten the Screw tighter than
before.
• Do this test again, until the seat post
does not move in the seat tube.
A
B
