19
Switching Rear Wheel Sprocket - continued
Note: The Bicycle comes from the factory with the Freewheel Sprocket in use.
Step One:
• Begin by loosening the Adjuster Nut (20). Remove Nut and Bracket (19).
• Remove the Axle Nut (16) Washer (17) and Adjuster Stud (18). Remove Axle Nut
and washer from opposite side.
16
17
18
22
19
20
Freewheel Gear (22)
Note: The Freewheel Gear will turn in one direction on the wheel.
To Next Page
