Components
No. Description No. Description
1 Frame 20 Adjuster Nut
2 Front Wheel Assembly 21 Fixed Sprocket
3 Tire (x2) 22 Freewheel Sprocket
4 Tube (x2) 23 Front Brake
5 Rear Wheel Assembly 24 Rear Brake
6 Fork 25 Right Brake Lever
7 Crank Arm Set 26 Left Brake Lever
8 Crank Bearing Set 27 Stem
9 Sprocket 28 Handlebar
10 Chain 29 Grips (x2)
11 Chain Guard 30 Front Refl ector
12 Pedal (RH) 31 Seat Post Clamp
13 Pedal (LH) 32 Seat Post
14 Kickstand 33 Rear Refl ector
15 Wheel Retainer (x2) 34 Seat Post Hardware
16 Axle Nut (x4) 35 Seat
17 Rear Axle Washer (x2) 36 Head Set Bearing Set
18 Adjuster Stud
19 Adjuster Bracket
Parts Assembly List
