Huffy 700c - Page 20

20
Switching Rear Wheel Sprocket - continued
Step Two:
• Slide wheel forward in frame and remove the chain from the sprocket.
• Remove the Wheel from the frame.
• Turn the wheel around so that the Fixed Gear Sprocket (21) is on the Right Side.
• Put chain on the Fixed Gear sprocket as you slide the axle into the frame.
• Install Adjuster Stud (18), Bracket (19) and Adjuster Nut (20) hand tight.
• Install Washers (17) and Axle Nuts (16) on both sides hand tight.
21
19
20
16
17
18
Fixed Gear (21)
Note: The Fixed Gear will not turn on the wheel.
IMPORTANT:
Proceed to Chain Adjustment on next page.
