Components
No. Description No. Description
1 Frame 19 Seat Post
2 Front Wheel Assembly 20 Rear Reector
3 Tire (x2) 21 Seat Post Hardware
4 Tube (x2) 22 Seat
5 Rear Wheel Assembly 23 Rear Brake
6 Fork 24 Front Brake
7 Crank and Spindle Set 25 Head Set Bearings
8 Lower Brake Cable Coupler (various models) 26 Gyro Head Set
9 Chain 27 Front Reector
10 Chain Guard 28 Handlebars
11 Handlebar Stem 29 Upper Brake Cable Coupler (various models)
12 Right Pedal 30 Right Brake Lever
13 Left Pedal 31 Left Brake Lever
14 Kick Stand 32 Grips (x2)
15 Wheel Retainer (x2) 33 Rear Axle Nut (x2)
16 Front Axle Nut (x2) 34 Rear Pegs (various models)
17 Front Pegs (various models) 35 Bell (not shown - if equipped)
18 Seat Post Clamp
Parts Assembly List
