Parts Assembly List
No. Description No. Description
1 Frame 18 Seat Post
2 Stem 19 Seat Clamp
3 Battery Pack and Mount 20 Crank & Spindle Set
4 Fork 21 Pedal (Left & Right Set)
5 Front Wheel Assembly 22 Chain
6 Tire (x2) 23 Rear Chain Adjuster
7 Tube (x2) 24 Rear Drive Motor
8 Front Axle Nut 25 Rear Motor Wheel Assembly
9 Rear Axle Nut 26 Rear Brake Caliper
10 Front/Rear Brake Disc (set of 2) 27 Front Brake Caliper
11 Grip Set 28 Front Light
12 Brake Hand Levers 29 Head Set Bearing
13 Throttle Assembly 30 Control Display
14 Seat 31 Bell (various models)
15 Rear Light * Handlebar Reector (various models) not shown
16 Chainguard * Seat Reector (various models) not shown
17 Battery Charger * Kickstand (not shown)
NOTE: Models with Display please see manual KD58C-LCD
included with this product
