Humboldt Digital MasterLoader HM-3000.3F - Device ID

Humboldt Calibration Instrumentation Chart
23
Load Cell Part# English Gain Metric Gain
(divisions) (divisions)
10,000 lb. (50kN) HM-2300.100 10000 4 5000 4
5,000 lb. (25kN) HM-2300.050 5000 2 2500 4
2,000 lb. (10kN) HM-2300.020 20000 8 10000 4
1,000 lb. (5kN) HM-2300.010 10000 4 5000 4
500 lb. (2.5kN) HM-2300.005 5000 4 2500 4
LVDT Transducer
0.4" (10.0mm) HM-2310.04 4000 2 10000 2
1.0" (25.4mm) HM-2310.10 1000 1 25000 2
2.0" (50.8mm) HM-2310.20 2000 1 50000 4
Pore Pressure
100psi (1000kPa) HM-2300.100 1000 1 1000 1
Device ID
Factory set device ID to 1, if multiple units are connect to a single computer
a unique device ID for each unit has to be establish for the computer to
recognize the correct instrumentation and the correct motors.
To set the Device ID the HM-3000 will use, press until you see this
screen:
Press you will see this screen:
Press you will see this screen:
* REVIEW LAST TEST
* RUN TEST
* MORE SETUP
* ENGINEERING SETUP
* SENSOR LIMITS OFF
* RAW_DATA
* MORE SETUP
